Ultra-stable, high precision (ppm ) fluxgate technology DS Series current transducer for non-intrusive, isolated DC and AC current measurement up to 2000A
Features：
20 ppm linearity
15 ppm offset 10V output in BNC connector @ 2000A
Fluxgate, closed loop compensated technology with fixed excitation frequency and second harmonic zero flux detection for best in accuracy and stability Industry standard DSUB 9 pin connection
Green diode for normal operation indication
Full aluminum body for superior EMI shielding and extended operating temperature range
京公网安备 11010802024102号
产品介绍
丹麦Danisense磁通门电流传感器-DS2000UBLA-10V
丹麦Danisense磁通门电流传感器-DS2000UBLA-10V
丹麦Danisense磁通门电流传感器-DS2000UBLA-10V
详细资料
丹麦Danisense磁通门电流传感器-DS2000UBLA-10V
Ultra-stable, high precision (ppm ) fluxgate technology DS Series current transducer for non-intrusive, isolated DC and AC current measurement up to 2000A
Features：
20 ppm linearity
15 ppm offset
10V output in BNC connector @ 2000A
Fluxgate, closed loop compensated technology with fixed excitation frequency and second harmonic zero flux detection for best in accuracy and stability
Industry standard DSUB 9 pin connection
Green diode for normal operation indication
Full aluminum body for superior EMI shielding and extended operating temperature range
Large aperture f68mm for cables and bus bars
Applications:
MPS for particles accelerators
Gradient amplifiers for MRI devices
Stable power supplies
Precision drives
Batteries testing and evaluation systems
Power measurement and power analysis
Current calibration purposes
